Mini Camera Link 2 Meter Standard Male MDR to Mini Male SDR Cable

Product Details:

Place of Origin:China
Brand Name:DHT
Certification:CE/ROHS/FCC/SGS/UL
Model Number:CL0200-SS

Payment & Shipping Terms:

Minimum Order Quantity:50pcs
Price:negotiation
Packaging Details:1 piece  per PE Bag then 50pcs per carton
Delivery Time:3 - 7 working days
Payment Terms:T/T or Paypal
Supply Ability:3,000pcs per month


Detailed Product Description

Product Name:Camera Link CableSheath Material:PVC
Range Of Application::Machine Vision ImagingType:High Speed Data Cable
Conductor Material:CopperConductor Type:Solid
Material Shape:Round Wire1meters:85MHz

Mini Camera Link 2 Meter Standard Male MDR to Mini Male SDR Cable


Product Description:


Camera Link Cable, 2 Meter, Standard Male (MDR) to Mini Male (SDR)

Features:

  • Length:  2 meter

  • Connectors:  Standard Male (MDR) to Mini Male (SDR)

  • Over molded connectors and thumbscrews for strain relief

  • High Flex Black Cable

  • Supports Power over Camera Link (PoCL)


Equivalent to CEI part #MVC-1-2-5-2M

compatiable with 3M Molding cables:

  • Shrunk Delta Ribbon (SDR) Cable Assembly, 1MD26-X5XX-00C-XXX Series

  • Shrunk Delta Ribbon (SDR) Cable Assembly, 1SD26-X1XX-00C-XXX Series

  • Shrunk Delta Ribbon (SDR) Cable Assembly, 1MF26-L560-00C-XXX

  • Shrunk Delta Ribbon (SDR) Cable Assembly, 1MF26-L5XX-00C-XXX

  • Shrunk Delta Ribbon (SDR) Cable Assembly, 1MG26-LFW0-00C-XXX

  • Shrunk Delta Ribbon (SDR) Cable Assembly, 1SF26-L1XX-00C-XXX



Camera Link cable connector connection type including:

MDR Male Straight Exit, MDR Female Straight Exit, MDR Male Low Profile R/A Exit UP, MDR Male Low Profile R/A Exit DWN, HDR / SDR Male Straight Exit, HDR / SDR Male R/A Exit UP w/Recessed Screws, HDR / SDR Male R/A Exit DOWN W/Recessed Screws, MDR Male Ext. Profile R/A Exit UP, MDR Male Ext. Profile R/A Exit DWN, MDR Male Exit RIGHT w/Recessed Screws MDR Male Exit LEFT w/Recessed Screws, HDR / SDR Female Straight Exit, 14P HDR / SDR PoCL Lite Straight Exit w/Recessed Screws, MDR Latch Type Straight Exit, HDR / SDR Male Exit RIGHT w/Recessed Screws, HDR / SDR Male Exit LEFT w/Recessed Screws, HDR / SDR Male R/A UPExt. Profile w/Recessed Screws, HDR / SDR Male R/A DWN Ext. Profile w/Recessed Screws.


Camera Link Cables - Used in very high speed data transmission, frame grabber interfaces, etc.

Male and female Camera Link cable assemblies

Quick release latches or High Quality Thumbscrews locking type available.

1meter to 15meters lengths available,Straight connection and Right angle available

Cables can be customized for unique requirements

High flex cable and standard cable available Incorporates 26-position 3M MDR connectors
