|Place of Origin:||China|
|Minimum Order Quantity:||50pcs|
|Packaging Details:||1 piece per PE Bag then 20pcs per carton|
|Delivery Time:||3 - 7 working days|
|Payment Terms:||T/T or Paypal|
|Supply Ability:||3,000pcs per month|
Detailed Product Description
|Sheath Material:||PVC||Range Of Application:||Automation|
|Conductor Type:||Solid||Insulation Material:||PVC|
|Material Shape:||Twisted Pair||Color:||Black / Beige / OEM|
|Length:||5meters||Pocl:||Power Over Camera Link|
|Max Length:||10meters||Connector:||3m SDR Solder Type|
High Flex SDR Mini Camera Link Cable Assembly 5.0 meters SDR Right Angled Male Cable Available
Camera Link cable assemblies for industrial motion system and frame grabber applications. The Camera Link Standard is a set of electrical requirements that cables must meet to be used in a Camera Link. High-flex cable assemblies meet or exceed each of the specifications of the Camera Link standard. Additionally, deliver exceptionally long life of at least 10 million flex cycles, providing flexibility for moving video applications. We manufacture Camera Link cable assemblies to any length for custom fitting. The over mold jacket is extremely durable, flexible, and water-proof. Each conductor features ultraflex, finely stranded wires, with dual shielding for optimum signal quality and speed. The cable OD9.5MM, with the length specified by the customer.
Variety of interace type and cable length available:(SDR/HDR)
Mini SDR to Mini SDR
Standard MDR to Mini SDR
Standard MDR to Standard MDR
Right angle MDR to Mini SDR
Right angle MDR to Standard MDR
Standard MDR to 90 degree Mini SDR
Mini SDR to 90 degree Mini SDR
1, Proven Quality High Flex life Cable(All our Camera Link cable assemblies meet High Flex or Robotics specification)
2, Lifetime test passing over 3million cycles and progressing.(Flex test term: Locomotive track / Flex Rdius / Flex Speed)
3, Ultra low noise Mini Camera Link Cable Assemblies
4, All 1Meter~6Meters length time frequency at 85Mhz,100%tested.(Max length 10meters time frequency @ 70Mhz)
5, PoCL and Non PoCL type available
6, Straight, Up and Down Directions for SDR mini connectors
7, Also available at High Frequency version to reduce, if not to eliminate, repeater requirements
8, RoSH and UL approval
1, Industrial Control
2, Factory Automation
3, Machine Vision system and Camera Link camera SDR / HDR /POCL and no-POCL interface
4, Digital Camera Cables are primarily used in machine vision applications for the connection
5, Use in other LVDS signaling applications is also possible.
1, Factory experiecne offer OEM/ODM service
2, Specializes in designing, developing and manufacturing high speed cable assembly:Machine Vision Cable,Automation Cable,Control Cable,Chainflex Cable etc.
3, Material from USA,JAPAN,TAIWAN
4, All cables 100% tested,1~2year Guarantee.
5, Response Quick and Fast Delivery
6, 100% Sample test before ordering.
