14520-EZAB-030-0EC MDR 20Pin D-Sub Cables Assembly Hi Speed 3M Camera Link Cables
1, Customized Industrial Camera Data Cable 3M, Iron Shell Assembly MDR Connector,with POCL power over Camera Link cable for options.
2, High-speed types are suitable for a clock frequency @85MHz
3, Cable is a high flex straight camera link cable.The cable construction adheres to Camera Link specifications and are Certified to Camera Link Committee Standards. By combining the most advanced materials and sophisticated building techniques, we provides the high flex industrial assemblies available,including Camera link,USB, U3,Firewire,Gige Vision,Hirose series cable assemblies. These assemblies are designed to function within a broad range of temperature and environmental conditions and may be used in either static or flex applications.
4, Max Length 15meters High speed transmission well shielded,low attenuation,low noise
5, Hiflex,can be used in chain system.
7, Working temperature -40℃~+80℃
8, Confirms to the UL standard,confirms to RoHS directives
8, Confirms to the CAMERA Link interface specifications and compatiable with all industrial camera with camera link interface
Compatiable part number:
MDR 20PIN :
MDR 36PIN :
Attenuation (28AWG / 30AWG)
Cable Length Min: 0.3meters ~ Max: 15.0meters
We have many solutions for machine vision data transmission and connection to solve the complex problem,worth of your contacting.welcome.
