|Place of Origin:||China|
|Certification:||CE RoHS UL|
|Model Number:||SDR 26pin Female to Male conjunction|
|Minimum Order Quantity:||50pcs|
|Packaging Details:||individual packing|
Detailed Product Description
|Connector:||SDR 26pin Female To Male Conjunction||Cable:||High Flex|
Mini Camera Link Extension Cable Assemblies Ultraflex with 26Pin SDR Male to SDR Female Coupled connector
RoHS Compliant Camera Link Extension Cable Ass'y for base and mediunm configuration
MINI Camera Link cable one end with standard MDR 26P Male connector,the other end with coupled 26pin female connector,with Power over for options,and 90 degree right angle is available,all material from USA ,Japan and Taiwan brand supplier,3M original connector to confirm the high speed transmission,cable body is ultraflex for chain system,can work in -40℃ ~+ 80℃.
We have many solution for machine vision data transmission and connection to solve the complex problem,worth of your contacting.welcome.
Engineering support and quick-turn manufacturing gets your custom Camera Link cables to you quickly and efficiently .
We manufacture an endless variety of Camera Link cable assemblies.
You can mix and match per MDR and SDR standards, or create a completely customized Camera Link cable or multi-leg harness, limited only by your imagination and engineering constraints.
· Internal to External Camera Link Cables
· Female SDR to Male SDR
· Female SDR to Male MDR
· Female SDR to Multi-Legged MDR and / or SDR
· Female SDR to Right Angled SDR or MDR
· Right Angled Female SDR to......
PoCL: Power over Camera Link
Power over Camera Link® cable "allows the camera to be powered by the frame grabber through the single Camera Link cable" (AIA, 2010).
PoCL cable is standard on all Camera Link cable assemblies
30 AWG PoCL cable
28 AWG PoCL cable
