High Flex Camera link Cable Assembly MDR to MDR 5meters 85Mhz for static or Dynamic application millions cycles

Product Details:

Place of Origin:China
Brand Name:DHT
Model Number:PoCL0500-SS

Payment & Shipping Terms:

Minimum Order Quantity:50pcs
Packaging Details:1 piece  per PE Bag then 20pcs per carton
Delivery Time:3 - 7 working days
Payment Terms:T/T or Paypal
Supply Ability:3,000pcs per month

Detailed Product Description

Sheath Material:PVCRange Of Application:Automation
Type:InsulatedConductor Material:Copper
Conductor Type:SolidInsulation Material:PVC
Material Shape:Twisted PairColor:Black / Beige / OEM
Length:5metersPocl:Power Over Camera Link
Max Length:10metersConnector:3m MDR 26 Solder Type

High Flex Camera link Cable Assembly MDR to MDR 5meters 85Mhz for static or Dynamic application millions cycles


High Flex Camera Link Cable assemblies is high flex straight camera link cable.The cable construction adheres to Camera Link specifications and are Certified to Camera Link Committee Standards. By combining the most advanced materials and sophisticated building techniques, we provides the high flex industrial assemblies available,including Camera link,USB, U3,Firewire,Gige Vision,Hirose series cable assemblies. These assemblies are designed to function within a broad range of temperature and environmental conditions and may be used in either static or flex applications.

Camera Link cable assemblies for industrial camera and frame grabber applications. High-flex cable assemblies meet or exceed the standard specifications of the Camera Link standard. Additionally, deliver exceptionally long life of at least 5~10 million flex cycles, providing flexibility for moving applications. We manufacture Camera Link cable assemblies to any length for custom fitting. The over mold jacket is extremely durable, flexible, and water-proof. Each twisted conductor features ultraflex, finely stranded wires, with dual shielding for optimum signal quality and speed. The cable OD 8.0 and OD 9.5MM, with the length specified by the customer.


1, Proven Quality High Flex life Cable(All our Camera Link cable assemblies meet High Flex or Robotics specification)
2, Lifetime test passing over 3million cycles and progressing.(Flex test term: Locomotive track / Flex Rdius / Flex Speed)
3, Ultra low noise Mini Camera Link Cable Assemblies
4, All 1Meter~6Meters length 85Mhz,100%tested.(Max length 10meters at 70Mhz and length 15meter 40Mhz)
5, PoCL and Non PoCL type available
6, Straight, Up and Down Directions for SDR mini connectors
7, Also available at High Frequency version to reduce, if not to eliminate,  repeater requirements

8, PVC Jacket

9, Color: Black
10,RoSH and UL approved


Attenuation (28AWG)


Frequency bandwidth

cable length(M)less5.86.0~8.08.1~1010.1~1515.1~22
Frequency bandwidth(MHZ)8575664022

Cable Length Min: 0.3meters ~ Max: 15.0meters


1, Industrial Control
2, Factory Automation
3, Machine Vision
4, Digital Camera Cables are primarily used in machine vision applications for the connection
5, Use in other LVDS signaling applications is also possible.


1, Factory experiecne offer OEM/ODM service
2, Specializes in designing, developing and manufacturing high speed cable assembly:Machine Vision Cable,Automation Cable,Control Cable,Chainflex Cable etc.
3, Material from USA,JAPAN,TAIWAN
4, All cables 100% tested,1~2year Guarantee.
5, Response Quick and Fast Delivery
6, 100% Sample test before ordering.
