Right Angle Camera Link Cable SDR 26 pin Full Shielded Cable Harness PVC Outshell

Product Details:

Place of Origin:CN
Brand Name:DHT
Certification:UL CE RoHS
Model Number:CL0200-SLM

Payment & Shipping Terms:

Minimum Order Quantity:50pcs
Packaging Details:PE bag and cartons
Supply Ability:500pcs per week

Detailed Product Description

Cable:11 Individually Shielded Twisted PairsConnector:26 Pos MDR Or SDR (HDR)  Straight Or Right Angle
Color:BlackLocking Type:With Screw
Length:1~10metersHigh Flex Cable:Yes

Right Angle Mini Camera Link Cable SDR 26 pin Full Shielded Cable Harness PVC Outshell

Product Description:

DHT camera link right angle cable is according to Camera Link AIA Committee Standards. we can provides the robust industrial assemblies available. These right angles are designed to function within limited equipment space and the robust features can be used to the equipment of temperature and environmental conditions and may be used in either static or flex applications.

The unique right angle overmolding available in up, down, left and right orientations allows for immediate turns behind the interface that are specific to your application needs eliminating the need for minimum bend radius concerns. The common configuration consists of a right angle on the camera end and an overmolded straight connector on the equipment end. However both connectors are available with a right angle.

Our High Flex extension cables offer system versatility and convenience when required to extend your current cable length. Both the plug and the receptacle connectors feature durable overmolded strain reliefs. The receptacle end is completed with 4/40 jacknuts to ensure locking and proper, constant connection through motion and vibration. Right angle and low profile right angle assemblies are also available in the extension format.

The latch style locking offers a quicker connect/disconnect time for the plug end than standard thumbscrews. Cables are available with latches on both ends and with latches on one end and thumbscrews on the other.

Mini Camera Link (SDR) right angled Connectors

The Mini Camera Link  (SDR) Connectors feature a high density .8mm pitch interface and a low height profile of 0.5mm. Using the same reliable ribbon contact system and polarized steel shell interface as the  Camera Link™ (MDR), the SDR connectors offer the same performance, but in a miniature size. The Shrunk Delta Ribbon (SDR) connector's innovative packaging design allows for drop-in replacement of existing MDR Camera Link applications. The SDR connectors feature 30u" gold contact, polarized, metal EMI/ESD interface, jacksocket hardware, and RoHS compliance.

DTH Camera Link Cable Features

  • Cable: 11 Individually Shielded Twisted Pairs

  • Designed to surpass 5 million flex cycles

  • AIA Certified

  • Robust High Flex cable

  • Low skew

  • Long distacne

  • OEM

  • 360 Degree shielding

  • Right angle interfaces

  • Quick latch style locking

  • RoHS Compliant

DHT Camera Link Connections:

  • Durable overmolding

  • Thumbscrew locking

  • Connector A: 26 Pos MDR or SDR (HDR)  Straight or Right angle

  • Connector B: 26 Pos MDR or SDR (HDR)  Straight or Right angle

We can offer above desciped cable with Power Over Camera Link Cable
